Angle Pads Instructions for FOSTEX, Denon, & E-MU Easy installation! /pair Copyright © 2007-2017 Lawton Audio.  All rights reserved.

Step 1: Remove The Stock/Factory Pads

The pads attach to the headphone unit via a plastic ring which has 4 teeth that fit into a slot in the headphone frame.

To remove: select a point between two of the teeth, slipping your thumb under the plastic ring, and pinching the top of the pad firmly with your index finger. Gently turn/rotate/twist in a counter-clockwise motion. The teeth will slide along the slot until they all release simultaneously. The pad and the plastic ring will separate together from the headphone.














Step 1: Notes & Tips

NOTE: Pads normally come off very easily using the pinch and twist method. There is a small percentage of these plastic rings that can be a little more stubborn than others. For these cases, use caution and make sure you do NOT overly stress the teeth by pulling up on them too hard.

TIP: For these unusual cases, simply peel the pad itself right off the headphone, separating it rom the plastic ring, leaving the ring attached to the frame for now. This will not harm your pad, it will slide right off the ring. Then using a screwdriver with a flat head, push firmly against one of the teeth in the counter-clockwise direction toward the larger end of the slot; the ring should now free itself.






Step 3: Re-Install Your Angle Pads

Insert the 4 teeth of the plastic ring into the larger end of the pad slots. With the palm of your hand, press the pad firmly against the frame and then turn in a clockwise direction until they lock into place.

Align the pads correctly so that the thinner end with the seam is in the front (toward your face when wearing them). Rotate the pads on the plastic ring so that the seams line up with the metal dimples/caps where the frame attaches to the cups assembly in the front.  The Pads should rotate fairly easily for you on the plastic rings until the seams are so aligned.

That’s it! Happy listening.



































How To Install Your Lawton Audio Angle Pads. It’s Easy!

Skill Level: Anyone!

Time: 5 minutes.

Tools Needed: Your hands!
















Step 2: Attach Angle Pads to Plastic Rings

Slide the plastic ring inside the flap or “lip” of the underside of the Angle Pad, with the teeth projecting out and up from the bottom of the pad.

Once you have wrapped the leather lip around as far as it will allow by hand, use a smooth-edged object like a spoon handle (nothing sharp!), and slip it under the lip. Gently slide the spoon handle along the edge of the plastic ring, guiding the remaining leather over the edge until it is completely seated inside. Make sure the leather does not cover over any of the plastic teeth. Now you are ready to install!
